How Big is a Harley Davidson?

Harley Davidson motorcycles often stand out due to their size. The proceeding information should give you a clearer perspective as to their scale.

Harley Davidson Dimensions: Sportster 883 Iron XL883N

The 883 Iron XL883N is 85.80 in. (2179.32 mm) long, 32.32 in. (820.93 mm) wide and 43.60 in. (1107.44 mm) high. The seat height: 25.30 in. / 642.62 mm (Laden2): 26.30 in. / 668.02 mm (Unladen). The rake (steering head) is 29.6 degrees and the ground clearance is 3.90 in. (99.06 mm).

The trail is 4.60 in. (116.84 mm) and the fork angle is 29.6 degrees. The wheelbase is 60.0 in. (1524.0 mm). The tires are Dunlop Harley Davidson Series, blackwall (front: D401F 100/90-19 57H; rear: D401 150/80B16 71H). The fuel capacity is 3.30 gallons (12.49 L). The weight (in running order) is 565 lbs. (256.28 kg).

Harley Davidson Dimensions: Sportster 883 Low XL883L

The length is 89.10 in. (2263.14 mm) and its width is 35.20 in. (894.08 mm). The height of the 883 Low XL883L is 45.70 in. (1160.78 mm). The seat height: 25.30 in. / 642.62 mm (Laden2) / 26.30 in. / 668.02 mm (Unladen).

The ground clearance is 3.90 in. (99.06 mm) and the rake (steering head) is 29.6 degrees. The fork angle is 28.6 degrees and the trail is 4.60 in. (116.84 mm). The wheelbase is 60.0 in. (1524.0 mm).

Its tires are Dunlop Harley Davidson Series, blackwall (front: D401F 100/90-19 57H; rear: D401 150/80B16 71H). The weight (running order) is 583 lbs. (264.45 kg). The fuel capacity is 3.30 gal (12.49 L).

Harley Davidson Dimensions: FXDWG Dyna Wide Glide

The length is 94.0 in. (2387.60 mm) and the width is 37.20 in. (944.88 mm). The height is 47.80 in. (1214.12 mm). The seat height: 25.50 in. (647.70 mm) Laden2 / 26.70 in. (678.18 mm) Unladen. The rake (steering head) is 34 degrees and the ground clearance is 4.20 in. (106.68 mm).

The trail is 5.20 in. (132.08 mm) and the fork angle is 36 degrees. The wheelbase is 68.30 in. (1734.82 mm), while the tires are Dunlop Harley Davidson Series, bias blackwall (front: GT502 F 80/90-21 54V; rear: GT502 180/60B17 75V). The fuel capacity is 4.70 gal (17.79 L). The weight (running order) is 665 lbs. (301.64 kg).

Harley Davidson Dimensions: Cross Bones FLSTSB

The length of the Cross Bones FLSTSB is 90.50 in. (2298.70 mm) and the height is 52.60 in. (1336.04 mm. The width is 38.10 in. (967.74 mm). The seat height: 26.60 in. (675.64 mm) for Laden2; 30.10 in. (764.54 mm) for Unladen.

The fork angle is 24.2 degrees and the ground clearance is 4.90 in. (124.46 mm). The rake (steering head) is 32.5 degrees. The wheelbase is 64.50 in. (1638.30 mm) and the trail is 6.30 in. (160.02 mm).

The tires are Dunlop Harley Davidson Series (bias blackwall front: D402F MT90B16 72H: rear: radial blackwall D401 200/55R17 78V). The weight (running order) is 731.25 lbs. (331.70 kg). Fuel capacity is at 5 gal (18.93 L).

The Harley Davidson dimensions stated here are just examples. When you go through the various models, you’ll see a lot more variety.
